Weld Neck Flange:

This type of flange is welded to the pipe or fitting, providing a strong and permanent connection. It is commonly used in high-pressure applications and can be used for both high and low temperatures.

Slip-On Flange:

This type of flange slides onto the pipe or fitting and is then welded in place. It is a popular choice for low-pressure applications and can be used for both high and low temperatures.

Blind Flange:

A blind flange (also called a ‘closure plate flange’) is installed at the end of a piping system to terminate a pipe. It has no centre hole (bore), so there is no flow through the flange. A blind flange may be used for isolating a pipe, valve, or pressure vessel.

Socket Weld Flange:

This type of flange has a socket for the pipe to fit into, creating a smooth flow path. It is commonly used in high-pressure applications and can be used for both high and low temperatures..

Lap Flange:

Lap Joint Flanges are used with a stub end, which is welded to the pipe. Alloy Steel Lapped Joint Flanges are designed in a way that they swing over the pipe without the need to be welded.

Plate Flange:

Manufactured with procedures that are compliant with global flange standards, our Stainless Steel Plate Flanges are free from any cracks and deformities, due to which they last longer and provide an extended service lifespan. Our Carbon Steel Plate special maintenance needs,and added advantage to use them.

Tongue & Groove:

Tongue & Groove Flange, the Tongue Flange is manufactured with a raised ring that is machined into its face. The Groove Flange is produced with a matching depression machined onto its face. In order to have a watertight connection, it is important to match the faces of these flanges.

Ring Type Joint Flanges:

(RTJ) that are best-in-class. A Ring type joint flange(RTJ) is a machined metallic ring with a deep groove cut into its face. This groove rests a metal ring which gets compressed when the connecting bolts of the flange are tightened.

Orifice Flanges:

An orifice flange is used to measure the flow of the fluid conveyed by the pipeline via a flow nozzle positioned on the flange itself. Pairs of pressure tappings are machined onto the orifice flange, making separate tappings on the pipe wall unnecessary.

Threaded Flange:

This type of flange has threads on the inside diameter, allowing it to be screwed onto a threaded pipe or fitting. It is commonly used in low-pressure applications and can be used for both high and low temperatures.
